Acoustic Camera Systems - Buying Guide
คู่มือการซื้อระบบกล้องอะคูสติก
Introduction
Acoustic cameras visualize sound sources in real-time, making them invaluable for noise source identification, product development, and quality control. This guide will help you understand the technology and choose the right system for your applications.
กล้องอะคูสติกแสดงภาพแหล่งกำเนิดเสียงแบบเรียลไทม์ ทำให้มีคุณค่าอย่างมากในการระบุแหล่งเสียง การพัฒนาผลิตภัณฑ์ และการควบคุมคุณภาพ
Pro Tips
- 💡Request demonstration with your specific application in mind
- 💡Consider measurement distance and environment (indoor/outdoor)
- 💡Evaluate software usability - you will use it frequently
- 💡Factor in training costs - these systems require expertise
- 💡Check microphone calibration and maintenance requirements
- 💡Verify export formats for integration with other analysis tools
Technical Reference
Acoustic cameras (microphone arrays with beamforming processing) create real-time visual maps of sound source distributions overlaid on a camera image. Selection criteria include: frequency range (typically 500 Hz–20 kHz for vehicle and machinery NVH), spatial resolution (related to array aperture and frequency), number of microphone channels (32–128 for automotive, 16–32 for general use), beamforming algorithm (delay-and-sum, CLEAN-SC, DAMAS), distance range, and dynamic range. The Norsonic Nor848A features 64 microphones in a 0.6 m × 0.4 m planar array achieving approximately 5° spatial resolution at 5 kHz at 1 m distance.
Beamforming Algorithm Selection
Conventional delay-and-sum (DAS) beamforming is fast but produces sidelobes that can mask weaker sources near dominant sources. CLEAN-SC (source-coherent variant) iteratively removes the contribution of identified sources, providing cleaner maps with fewer artefacts — essential for vehicle NVH work with multiple simultaneous sources. DAMAS (Deconvolution Approach for the Mapping of Acoustic Sources) provides the highest resolution but requires longer computation.
Frequency Range & Array Size
Array aperture determines the lowest usable frequency: larger arrays work at lower frequencies. A 0.6 m aperture provides useful resolution from about 500 Hz. Upper frequency is limited by inter-microphone spacing (aliasing). For automotive wind noise (100–500 Hz), large in-duct arrays are required. For machinery source identification (500 Hz–8 kHz), compact 32-element arrays suffice.
